MODEL
|
NG18-1012
VPM
|
NG18-2024
VPM
|
NG18-3024
VPM
|
NG18-3048
VPM
|
NG18-4048
VPM
|
NG18-5048
VPM
|
|
Default Battery System Voltage
|
12VDC
|
24VDC
|
48VDC
|
|
INVERTER
OUTPUT
|
Rated Power
|
1000VA \ 1000W
|
2000VA \ 2000W
|
3000VA \ 3000W
|
3000VA \ 3000W
|
4000VA \ 4000W
|
5000VA \ 5000W
|
|
Surge Power
|
2000VA
|
4000VA
|
6000VA
|
6000VA
|
8000VA
|
10000VA
|
|
Waveform
|
Pure sine wave
|
|
AC Voltage Regulation (Batt.Mode)
|
220VAC~240VAC(Setting)
|
|
Inverter Efficiency(Peak)
|
90%~93%
|
|
Transfer Time
|
10ms(UPS \ VDE4105) \ 20ms(APL)
|
|
AC INPUT
|
Voltage
|
230VAC
|
|
Selectable Voltage Range
|
170~280VAC(UPS) \90~280VAC(APL) \ 184~253VAC(VDE
|
|
Frequency Range
|
50Hz \ 60Hz (Auto sensing)
|
|
BATTERY
|
Normal voltage
|
12VDC
|
24VDC
|
48VDC
|
|
Floating Charge Voltage
|
13.7VDC
|
27.4VDC
|
54.8VDC
|
|
Overcharge Protection
|
15VDC
|
30VDC
|
60VDC
|
|
SOLAR
CHARGER
& AC
CHARGER
|
Maximum PV Array Open Circuit Voltage
|
75VDC
|
145VDC
|
145VDC
|
|
PV Array MPPT Voltage Range
|
15~75VDC
|
30~120VDC
|
60~130VDC
|
|
Standby Power Consumption
|
2W
|
|
Maximum PV Array Power
|
625W
|
1500W
|
4000W
|
|
Maximum Solar Charge Current
|
60A
|
80A
|
|
Maximum Efficiency
|
98%
|
|
Maximum AC Charge Current
|
10A or 20A
|
20A or 30A
|
60A
|
|
Maximum Charge Current
|
70A
|
80A
|
140A
|
|
MECHANICAL
SPECIFICATIONS
|
Machine Dimensions (W*H*D)(mm)
|
225*355*92
|
272*355*100
|
297.5*468*125
|
|
Package Dimensions (W*H*D)(mm)
|
410*300*78
|
485*393*251
|
638*395*241
|
|
Net Weight(kg)
|
5
|
7.4
|
14
|
|
Gross Weight(kg)
|
5.5
|
9.5
|
16.4
|
|
OTHER
|
Humidity
|
5% to 95% Relativ Humidity (Non-condensing)
|
|
Operating Temperature
|
0°C~50°C
|
|
Storage Temperature
|
-15°C -60°C
|
