Neexgent solar inverter 5.5kw with removable LCD hybrid solar inverter without battery

Neexgent High Quality 9bb Solar Panels 450w Half-cell Panels Solar 450w Mono Solar Panels

Type	Off grid solar inverter
Max.Power	5.5KW
Output Voltage	EU And US Standard
Certificate	PSE, FCC, CE, UN38.3, Msds, UL, SAA And ROHS
Lead Time	10 Days
Payment	T/T, L/C,Western Union
Warranty	25 Years

This device is a versatile inverter/charger that integrates the capabilities of an inverter, solar charger, and battery charger

to provide uninterrupted power in a compact, portable package.

Its extensive LCD display allows users to easily configure settings through accessible buttons. These settings include battery

charging current, priority between AC and solar charging sources, and acceptable input voltage levels tailored to various applications.

Product Features

Wide PV input range (120V dc - 500V dc) 80A MPPT SCC.
High efficiency pure sine wave inverter (PF=1).
Surges to 2X continuous power for 5 seconds for motor loads.
Intelligent 3 stage 60A AC battery charger.
Wide utility input range (90V ac ~ 280Vac) for unreliable grid even in the most challenging environments.
Intelligent functionality enables utility and solar input prioritization.
Field serviceable with replacement boards and spare parts.
Monitor, troubleshoot, or communicate with USB/RS 232.
System configures quickly into a compact, wall-mounted system.
This series of inverters can work without batteries when there is sunlight.

solar farm inverter solar inverter efficiency solar inverter installation solar storage inverter 5.5 kw solar inverter solar panels inverters

Tags:

Technical Specifications:

Model	NG5532VMII
Rated Power	5500VA/5500W
INPUT
Voltage	230 VAC
Selectable Voltage Range	170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range	50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)	230 VAC ± 5%
Surge Power	11000VA
Efficiency (Peak)	90%~93%
Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
Waveform	Pure sine wave
BATTERY
Battery Voltage	48VDC
Floating Charge Voltage	54VDC
Overcharge Protection	63VDC
SOLAR CHARGER & AC CHARGER
Max. PV Array Open Circuit Voltage	500VDC
Max. PV Array Power	120-450VDC
MPP Range ©operating Voltage	5000W
Max. Solar Charge Current	100A
Max. AC Charge Current	60A
Max. Charge Current	100A
PHYSICAL
Dimension, D x W x H (mm)	115x300x400
Net Weight (kgs)	10
Communication Interface	USB/RS232/RS485/Bluetooth/Dry-contact
ENVIRONMENT
Humidity	5% to 95% Relative Humidity (Non-condensing)
Operating Temperature	-10° C to 50° C
Storage Temperature	-15° C to 60° C

Approximate Back-Up Time Table:
