Panasonic Cell of the lithium-ion battery cell Panasonic NCR21700T is a high-precision, physical cell model with global validity.
|
Type |
21700 NCR Lithium Battery Cell |
|
Max.Power |
3.6V 5000mAh |
| Brand | Panasonic |
|
Certificate |
CB, UN38.3, BIS, UL, PSE, RoHS |
|
Lead Time |
10 Days |
|
Payment |
T/T, L/C,Western Union |
|
Warranty |
25 Years |
Panasonic Cell of the lithium-ion battery cell Panasonic NCR21700T is a high-precision, physical cell model with global validity.
High capacity and energy density
For providing stable power to devices, Panasonic NCR21700T 5000mAh 15A rechargeable battery offer 3.6V average operating voltage in order to guarantee maximum output power.
High discharge performance
Panasonic NCR21700T 5000mAh 15A battery provide powerful and constant power to the device or equipment, voltage drop less with load, the discharge curve is quiet stable from full to empty.
Applications widely
Panasonic NCR21700T 5000mAh 15A battery can be widely use to all products desire high capacity for longest running time. For example, Electric bikes, toys and electronics power devices.
Reliable and safe
Panasonic and Sanyo are world famous brand, also the leader of Li-ion 21700 battery technology, provide only reliable batteries, it is 100% safe by using the battery according to the cell datasheet.
Tags:
|
Standard Capacity |
5Ah |
|
Standard Voltage |
3.6V |
|
Battery Resistance |
≤14mΩ |
|
Standard Charge Current |
2A |
|
Max. Charge Voltage |
4.2±0.05V |
|
Max. Discharge Current |
12A |
|
Off Discharge Voltage |
2.5V |
|
Cycle Life (500 Times) |
>3.84Ah |
|
Charging Method |
CC-CV |
|
Weight |
68g±0.5 |
|
Operating Temperature |
0~45℃ |
|
Storage Temperature |
0~45℃ |
|
Charging Method |
CC-CV (constant voltage with limited current) |
|
Standard charge |
CCCV, 1.2A, 4.20 V, 200mA cut-off |
|
Rated charge |
CCCV, 2A, 4.20 V, 100mA cut-off |
|
Charging time |
Standard charge : 6h / 200mA cut-off |
|
Rated charge |
3.6h / 100mA cut-off |
|
Max. Discharge Current |
Max. Discharge rate: 2C (6.8A) |
|
Pulse current (5-6 sec.) |
12A |
|
Application |
Suitable for industrial and high drain application, such as Power Tool, eBike, R/C Hobby, drones, robot etc. |
