Neexgent Complete Set 30kw Solar Panels Solar Off Grid Solar System 30kw Off Grid Solar System Cost


Off Grid



Output Voltage

EU And US Standard



Lead Time

10 Days


T/T, L/C,Western Union


25 Years


30KW off-grid solar system, you can generate your own power and be completely independent from the electrical grid. This means that you will never have to worry about power outages or blackouts.


Cost savings:

An off-grid solar system can help you save money on your electricity bills by generating your own power. Over time, the cost of the system will be recouped through the savings you make on electricity bills.



Off-grid solar systems can be designed to suit a wide range of applications, from powering homes and businesses to running remote equipment and powering off-grid cabins and boats.


Low maintenance:

Off-grid solar systems require very little maintenance once installed. They have no moving parts and require only occasional cleaning of the solar panels.



Off-grid solar systems are designed to be durable and reliable, with a long lifespan. They are able to withstand harsh weather conditions and are resistant to damage from extreme temperatures.



30KW Off Grid Solar System Components30KW Solar System Off Grid DIY


30KW Solar Power System for Off Grid Living






Affordable 30KW Off Grid Solar System

200Ah Powerwall Battery

High cycle life
6000 cycles @80% DoD for effectively lower total of ownership cost


Longer service life
Low maintenance batteries with stable chemistry


Built in circuit protection
Battery Management System (BMS) is incorporated against abuse


Better storage
up to 6 months thanks to its extremely low self discharge (LSD)rate and no risk of sulphation.


Quickly recharge
Save time and increase productivity with less down time thanks tosuperior chargeldischarge efficiency.


Extreme heat tolerance
Save time and increase productivity with less down time thanks tosuperior chargeldischarge efficiency.


Lithium batteries provide more Wh/Kg while also being up to1/3 the weight of its SLA equivalent.


30KW Off Grid Solar System for Large Homes




OFF-grid Solar Inverter

• Smart LCD setting(Working modes, Charge Current, Charge voltage, etc.)

• Built-in MPPT solar charge controller 80A/100A/200A

• MPPT efficiency max 98%

• Powerful charge rate up to 140Amp

• DC start &Automatic Self-Diagnostic Function

• WIFI / USB monitoring function (wi-fi optional)

• Supporting AGS, BTS port • Compatible to generator














Best 30KW Off Grid Solar System

400W Full Cut Mono Solar Panels

Multi busbar technology
Better light trapping and current collection to improve, Effectivelyimprove the module's power output and reliability.


Higher output power
Module output power increased to 505W.


Low light performance
The special solar cell technology has excellent low light powergeneration performance.


Better resistance to hot spots
The use of half cell structure and special circuit design is less shadeloss, with better temperature coefficient and thermal spot resistanceability


Adaptability to harsh environments
High performance materials are suitable for coastal, farm, desert andother harsh environmental conditions, glass surface is anti-reflectiveand easy to clean, minimizing power generation losses caused by dirtand dust.









30KW Off Grid Solar System for Business

PV Mounting System

• Suitable for most roof types of tile, flat tile,slate tile, asphalt shingle tile


• A design that includes major specifications saves you inventory cost,quick and easy to install.


• Innovative design of rail connect base -support can effectively increasethe product strength, ensure the safety of the product use.


• Customization allowed according to customers' need to meetspecialinstallation requirements.





30KW Off Grid Solar System with Battery Backup

PV Combiner Box

• Two groups of independent PV array input and output for flexibleapplication in different connection     schemes


• Multiple PV input arrays each of which has a maximum currentof l0A


• High voltage fuse provided for the counterattack prevention ofeach PV input array


• Special high-voltage lightning protection device for the PV module


• Special high-voltage circuit breaker for output control of PV module


• Degree of protection of IP65 for meeting the need of outdoorinstallation













30KW Solar Power System for Remote Areas


• Good Electrical Conductivity electricity transmission, more energy saving


• Stable output current, no short circuit, circuit, etc.,high flexibility is noteasy to break


• Advanced equipment is adopted to ensure the low eccentricity of thecable and the safety of electricity use


• Flame retardant, no pungent smell when burning,durable andwear-resistant cable surface


• XLPO sheath, better drought resistance and temperature resistancethan ordinary cables


• XLPO sheath is made of waterproof and oil resistant material.The cable remains soft after a long immersion


30KW Off Grid Solar System with Generator Backup30KW Off Grid Solar System for Farm30KW Off Grid Solar System for Commercial Applications30KW Off Grid Solar System for Industrial Applications30KW Off Grid Solar System for Sustainable Living






Spec Description



Solar Inverter Model: PV35-10048 PRO Off Grid Inverter
Rated Power: 10000W
Split Phase Solar Inverter
•Big range of power: 10kw
•AC voltage: 220Vac
•Pure Sine Wave Ouput
•Battery DC Volt: 48V
•Built-in MPPT solar charge controller 200A
•MPPT effiency Max 98%
•Supporting USB,  AGS, BTS port
•Compatible to Generator



Solar Panel Model: Full Cut Mono 400W Solar Panel
Cell range: 6*9(182*182mm)
Size: 1725*1134*30mm
Carton Size: 1745*1155*75mm
Material: 3.2mm high transittance low iron tempered glass+High effiency solar cells+EVA+TPT, Aluminium frame
Junction box+MC4 cable



Mounting System Installation site : tile roor ( optional)
Extruded Aluminum Section
High Class Anodized Aluminum
one set brackets can mount 3pcs solar panels
 Wind Load :up to 130mph (60m/s)
Snow Load : up to 30psf (1.4kN/m2)



Powerwall Battery  Rated capacity :200.0Ah
Rated energy :5120Wh
Nominal voltage :51.2V
Internal resistance :≤40mΩ @1kHz AC
Standard charging voltage :57.6V
Recommended charging current :20.0A
Maximum continuous charging current :50.0A
Standard discharge current :50.0A
Maximum continuous discharge current
End-of-discharge voltage :44.0V
Communication :RS485/RS232
Cycle life :≥4000 times (0.2C
charge/discharge) 70%DOD


5 Combiner Box  4 input 1 output
>4 PV string inputs with max current 40a
>With PV dedicated high voltage lightning protection device 20KA-40KA
>Waterproof terminals
>Lightning Protection,it can reduce solar cable


Cable&Accessory 4 mm2: PVC insulated, single core, Red Meters 15
4 mm2: PVC insulated, single core, Black Meters 15
