Neexgent Complete Off Grid 8kw Home Solar System 8kw Solar Energy 8000w Solar Panel

Type

Off Gird

Max.Power

8000W

Output Voltage

EU And US Standard

Certificate

TUV, ISO, CE

Lead Time

10 Days

Payment

T/T, L/C,Western Union

Warranty

25 Years

8KW OFF-GRID SOLAR SYSTEM

Neexgent Solar Off grid Power System Home 8KW Solar Energy Panel Set for Household Appliances Commercail Industrial Use

**Working for the residential community,remote village and small house and soon.

**Providing stable electricity power by renewable energy from PV.

**When the utility is abnormal, the BSS runs in off-grid mode and provides sta ble power for load.

8kw off grid power8kw off grid system8kw off grid solar power systemoff grid solar batteriesoff grid solar panelsoff grid hybrid inverterbest batteries for off grid solar8kw off grid solar panel kit8 kw off grid solar system priceoff grid solar system cost

Tags:



No.

Product

Spec Description

Qty

1

Max-II-8000
8000VA/8000W
230VAC
48V
MPPT
Max.PV Array
Power:4000W*2
Max II Series
*Off-Grid Hybrid Solar Inverter
*Inbuilt MPPT solar controller 80A
*Max.PV input voltage 500VDC,PV
 input power 8000w
*WiFi built in monitoring
*These inverters can work without
batteries when there is the sun.
Can parallel operation 6units

1

2

Half cell MONO 450W
Solar panel(120)
Power:450W
Cell range: JA solar cell 6*20(182*91mm)
Size:1909*1134*35mm
Packing:31pcs/pallet
Pallet size:1910*1150*1300mm
Material: 3.2mm high transittance low iron tempered glass+High effiency solar cells+EVA+TPT,Aluminium frame
Junction box+MC4 cable

20

3

Lithium battery powerwall energy storage
(51.2V200AH)

Rated capacity :200Ah

Rated energy :10240Wh

Nominal voltage :51.2V

Internal resistance :≤40mΩ @1kHz AC

Standard charging voltage :57.6V

Recommended charging current :20.0A

Maximum continuous charging current :50.0A

Standard discharge current :50.0A

Maximum continuous discharge current :100.0A

End-of-discharge voltage :44.0V

Communication :RS485/RS232

Cycle life :≥4000 times (0.5C charge/discharge) 70%DOD

Charging :0~50℃

Discharge :-10~60℃

Shipping voltage: ≥51.2V

1

4

AC circuit breaker


50A 2 Set

5

DC circuit breaker 200A 1 Set
6 Combine box 6 INPUT+2 OUT PUT 2 Set
7 Solar panel connecter MC4 12
8 Cables
9 roof mount accessories
