Type |
Off Gird |
|
Max.Power |
5000W |
|
Output Voltage |
EU And US Standard |
|
Certificate |
TUV, ISO, CE |
|
Lead Time |
10 Days |
|
Payment |
T/T, L/C,Western Union |
|
Warranty |
25 Years |
5KW OFF-GRID SOLAR SYSTEM
Neexgent Solar Off grid Power System Home 5KW Solar Energy Panel Set for Household Appliances Commercail Industrial Use
**Working for the residential community,remote village and small house and soon.
**Providing stable electricity power by renewable energy from PV.
**When the utility is abnormal, the BSS runs in off-grid mode and provides sta ble power for load.
Tags:
|
No. |
Product |
Spec Description |
Qty |
||
|
1 |
NG5032VMIII 5000W 230VAC 48VDC 60A MPPT 48V80A 5000W |
NG VMIII Series *With removable screen support remote control, support W iFi & Bluetooth. * MPPT Volatge range: 120V-450V. * These inverters can work without batteries when there is the sun |
1 |
||
|
2 |
Half cell MONO 450W Solar panel（120） |
Power:450W Cell range: JA solar cell 6*20(182*91mm) Size：1909*1134*35mm Packing：31pcs/pallet Pallet size：1910*1150*1300mm Material: 3.2mm high transittance low iron tempered glass+High effiency solar cells+EVA+TPT，Aluminium frame Junction box+MC4 cable |
12 |
||
|
3 |
Lithium battery pack energy storage (51.2V100AH) |
Rated capacity :100.0Ah Rated energy :5120Wh Nominal voltage :51.2V Internal resistance :≤40mΩ @1kHz AC Standard charging voltage :57.6V Recommended charging current :20.0A Maximum continuous charging current :50.0A Standard discharge current :50.0A Maximum continuous discharge current :100.0A End-of-discharge voltage :44.0V Communication :RS485/RS232 Cycle life :≥4000 times (0.2C charge/discharge) 70%DOD |
1 |
||
|
4 |
|
30A | 2 Set | ||
|
5 |
DC circuit breaker | 100A | 1 Set | ||
| 6 | Combine box | 4 INPUT+2 OUT PUT | 1 Set | ||
| 7 | Solar panel connecter | MC4 | 4 | ||
| 8 | Cables | ||||
| 9 | roof mount accessories |
