• Pure sine wave output
• Self-consumption and deed in to the grid
• Programmable supply priority for PV, Battery or Grid
• User-adjustable battery charging current suits different types of batteries
• Programmable multiple operation modes: Grid-tie,Off-grid and grid-tie with backup
• Built-in timer for various mode of on/off operation
• Multiple communication for USB.RS232,Modbus and SNMP
• Monitoring software for rel-time status display and control
• Parallel operation up to 6 units for 10KW
• Pure sine wave output
• Self-consumption and deed in to the grid
• Programmable supply priority for PV, Battery or Grid
• User-adjustable battery charging current suits different types of batteries
• Programmable multiple operation modes: Grid-tie,Off-grid and grid-tie with backup
• Built-in timer for various mode of on/off operation
• Multiple communication for USB.RS232,Modbus and SNMP
• Monitoring software for rel-time status display and control
• Parallel operation up to 6 units for 10KW
Tags:
Technical Specifications:
|
Model |
HYG5532 |
|
PHASE |
1-phase in/1 phase out |
|
Max. PV INPUT POWER |
6500W |
|
Rated Output Power |
5500W |
|
Maximum Charging Power |
2880 W |
|
GRID TIE OPERATION |
|
|
PV INPUT (DC) |
|
|
Nominal DC Voltage/Max. DC Voltage |
360 VDC/500 VDC |
|
Start-up Voltage/lnitial Feeding Voltage |
116 VDC/150 VDC |
|
MPP Voltage Range |
120 VDC-450 VDC |
|
Number of MPP Trackers |
2/2x13A |
|
Maximum Input Current |
2/2x13A |
|
GRID OUTPUT (AC) |
|
|
Nominal Output Voltage |
208/220/230/240 VAC |
|
Output Voltage Range |
184-265 VAC* |
|
Nominal Output Current |
23.9A |
|
Power Factor |
> 0.99 |
|
EFFICIENCY |
|
|
Maximum Conversion Efficiency (DC/AC) |
96% |
|
European Efficiency@Vnominal |
95% |
|
OFF GRID OPERATION |
|
|
AC INPUT |
|
|
AC start-up Voltage |
120-140 VAC/180 VAC |
|
Auto Restart Voltage |
120-140 VAC/180 VAC |
|
Acceptable Input Voltage Range |
170-280 VAC |
|
Max. AC Input Current |
40A |
|
PV INPUT (DC) |
|
|
Max. DC Voltage |
500 VDC |
|
MPP Voltage Range |
120 VDC-450 VDC |
|
Number of MPPTrackers/Max. Input Current |
2/2x13A |
|
BATTERY Mode Output (AC) |
|
|
Nominal Output Voltage |
202/208/220/230/240 VAC |
|
Output Waveform |
Pure Sine Wave |
|
Efficiency (DC to AC) |
93% |
|
HYBRID OPER/EON |
|
|
PV INPUT (DC) |
|
|
Nominal DC Voltage/Max. DC Voltage |
360 VDC/500 VDC |
|
Start-up Voltage/lnitial Feeding Voltage |
116 VDC/150 VDC |
|
MPP Voltage Range |
120 VDC-450 VDC |
|
Number of MPP Trackers/Max. Input Current |
2/2x13A |
|
GRID OUTOUT (AC) |
|
|
Nominal Output Voltage |
202/208/220/230/240 VAC |
|
Output Voltage Range |
184-264.5 VAC* |
|
Nominal Output Current |
23.9A |
|
AC INPUT |
|
|
AC Start-up Voltage/Auto Restart Voltage |
120-140 VAC/180 VAC |
|
Acceptable Input Voltage Range |
170-280 VAC |
|
Max. AC Input Current |
30A |
|
BATTERY MODE OUTPUT (AC) |
|
|
Nominal Output Voltage |
202/208/220/230/240 VAC |
|
Efficiency (DC to AC) |
93% |
|
BATTERY& CHARGER |
|
|
Battery DC Voltage |
48V |
|
Max. Charging Current |
Default 60A |
|
GENERAL |
|
|
PHYSICAL |
|
|
Dimension, DxWxH (mm) |
110*450*445 |
|
Net weight (kgs) |
16 |
|
INTERFACE |
|
|
Communication Port |
RS-232/USB and CAN Interface |
|
ENVIRONMENT |
|
|
Humidity |
0 -90%RH |
|
Operating Temperature |
0to40℃ |
|
Altitude |
0-1000 m** |
